Cruz
LED downlight meets education lighting requirements
- Elegant look, die-cast aluminum housing with low height
- Integrated LED downlight with deep embedded reflector for improved glare control in office applications (UGR<19)
- High quality lighting color performance CRI90, R9>50 and SDCM3
- High system efficacy up to 140 lm/W
- Lumen switch via dip switch on driver, Ø95: 900lm, Ø150: 2000lm/ 1700lm/ 1500lm/ 1200lm, Ø200: 3200lm/ 2900lm/ 2650lm/ 2400lm
- Long 50.000 hours lifetime, reduce maintenance cost
Materials and Finish
Body: diecast aluminium for high efficient thermal management
Diffuser: polycarbonate
Smooth reflector in satinbrite finish with improved glare control in office applications
Trim RAL 9016
Installation and Mounting
Cruz can be installed tool free, directly out of the box into a wide range of ceiling types, suitable for 1-40mm ceiling thicknesses. 65~111mm overall recess depth to allow installation into low and restricted ceiling voids. Remote pluggable driver makes installation and maintenance quick and easy.
Specification
To specify state:
A highly efficient and sustainable LED downlight with low height provides harmonious light (UGR<19). 3 sizes available, cutout: Φ95mm, Φ150mm and Φ200mm. Total luminous flux: Φ95: 900lm, Φ150: 2000lm/ 1700lm/ 1500lm/ 1200lm, Φ200: 3200lm/ 2900lm/ 2650lm/ 2400lm, luminaire input wattage: 8W, 15W/13W/12W/10W and 23W/21W/19W/17W, CCT 4000K. Long 50.000hrs lifetime. CRI > 90, R9 > 50, SDCM 3. Class II electrical, IP54_IP20. Suitable for recessed mounting.
As Thorn Cruz
- New Product
▼ Cruz
| Description | Type | Wt (kg) | SAP Code | ||||||
|---|---|---|---|---|---|---|---|---|---|
| CRUZ 150 2000-940 | LED | 0.41 | 96295126 | ||||||
| CRUZ 200 3200-940 | LED | 0.61 | 96295127 | ||||||
| CRUZ 95 900-940 | LED | 0.27 | 96295125 |
