Luna 2
Ultra slim, integrated edge lit LED bulkhead provides harmonious light for indoor application.
- Edge lit LED design, ultra slim housing, 27mm height only
- CCT switch 830/840/857 via slide switch
- Phase cut dimming leads to more energy saving
- Long 50,000 hours lifetime, reduced maintenance cost
- Front side IP54 for indoor application
- Easy and reliable installation
Materials and Finish
Housing: polycarbonate, white finish (RAL 9016 )
Light guide panel: PMMA
Diffuser: opal polycarbonate
Installation and Mounting
Surface mounted.
Specification
To specify state:
Ultra slim housing, integrated edge lit LED Panel with opal diffusor provides harmonious light. 3 sizes available: Ø250*27mm, Ø300*27mm and Ø400*27mm. Total luminous flux: 1100 lm, 2100 lm and 2900 lm, luminaire input wattage: 12W, 18W and 25W, CCT switch 3000K/ 4000K/ 5700K via slide switch. Long 50,000hrs lifetime. CRI > 80. Phase cut dimmable. Front side IP54. Suitable for surface mount.
As Thorn Luna 2
New Product
LumExpress Product
eControl Product
▼ Luna 2
| Description | Type | Wt (kg) | SAP Code | ||||||
|---|---|---|---|---|---|---|---|---|---|
| LUNA 2 VCT 250 12W 830/840/857 WH DIM | LED | 0.10 | 96295113 | ||||||
| LUNA 2 VCT 300 18W 830/840/857 WH DIM | LED | 0.10 | 96295114 | ||||||
| LUNA 2 VCT 400 25W 830/840/857 WH DIM | LED | 0.10 | 96295115 |
