Circline
LED bulkhead meets lighting requirements for education
- Circle powder-coated aluminium body provides a high quality elegant look
- Integrated LED bulkhead with prismatic diffuser provides harmonious light (UGR<19)
- High quality light color performance CRI90, R9>50 and SDCM 3
- High system efficacy, up to 120lm/W
- Lumen switch via dip switch on driver, 3800lm/ 3100lm/ 2500lm
- Long 50,000 hours lifetime, reduces maintenance cost
Materials and Finish
Housing: aluminum, white finish (RAL 9016)
Base: steel, white finish (RAL 9016)
Diffuser: frosted polystyrene and prismatic polystyrene
Installation and Mounting
Surface mounted. Cable entry hole in the center of back base. Can be suspended using wire suspension accessory kit (to be ordered separately). 3 x 2 x 2.5mm² terminal block supplied for easy and quick looping.
Specification
To specify state:
Elegant look, integrated LED Bulkhead with prismatic diffusor provides harmonious light (UGR<19). Dimension: Ø450*80mm. Total luminous flux: 3800lm/ 3100lm/ 2500lm, luminaire input wattage: 32W/ 26W/ 21W, CCT 4000K. Long 50,000hrs lifetime. CRI > 90, R9 > 50, SDCM 3. Suitable for surface and suspended mounting.
As Thorn Circline
- New Product
New Product
LumExpress Product
eControl Product
▼ Circline
| Description | Type | Socket | Wt (kg) | SAP Code | |||||
|---|---|---|---|---|---|---|---|---|---|
| CIRCLINE 450 3800-940 | LED | LED | 2.35 | 96295124 |
