TONPAK LED G2 M & L
A 1-to-1 replacement for traditional floodlight up to 1000W.
- 1-to-1 replacement for a traditional 1000W floodlights
- Long life: 72,000 hours at Ta = 35 °C
- Minimal maintenance is required and no lamp replacement is needed during its lifetime
- Universal mounting bracket allows for easy angle adjustment
Materials and Finish
Body: Die-cast Aluminium painted in grey RAL9006
Lens: PC
Glass: 4mm thick toughened
Installation and Mounting
Surface mounted:
Place the LED floodlight and mounting bracket at the predefined installation location. Use two M12-size stainless steel screws and nuts to firmly fix the mounting bracket; connect mains power to the LED floodlight's power cable.
Specification
To specify state:
This surface-mounted, high-output area floodlighting LED luminaire has a die-cast aluminium body in grey (RAL 9006) and an efficient optical PC lens. It is designed for general-purpose and sports lighting applications and is available in two sizes with lumen packages ranging from 48,000 to 96,000. It has a high impact resistance (IP66 & IK08).
As Thorn TONPAK LED G2
- New Product
▼ TONPAK LED G2 M & L
| Description | Luminaire power (W) | Luminaire output (lm) | Type | Wt (kg) | SAP Code | ||||
|---|---|---|---|---|---|---|---|---|---|
| TONPAK LED G2 L 1176L49 840 A5 CL1 C5 | 550 | 88000 | LED | 13.60 | 22679237 | ||||
| TONPAK LED G2 L 1176L54 840 A5 CL1 C5 | 600 | 96000 | LED | 13.60 | 22679238 | ||||
| TONPAK LED G2 L 980L43 840 A5 CL1 C5 | 400 | 64000 | LED | 13.30 | 22679234 | ||||
| TONPAK LED G2 L 980L48 840 A5 CL1 C5 | 450 | 72000 | LED | 13.30 | 22679235 | ||||
| TONPAK LED G2 L 980L54 840 A5 CL1 C5 | 500 | 80000 | LED | 13.30 | 22679236 | ||||
| TONPAK LED G2 M 600L53 840 A5 CL1 C5 | 300 | 48000 | LED | 7.30 | 22679232 | ||||
| TONPAK LED G2 M 600L62 840 A5 CL1 C5 | 350 | 56000 | LED | 7.70 | 22679233 |
